Finishing Mower
Detailed introduction:
Finishing Mower
The FM mower has a lot of features which differ this unit from any others. This is suitable for any kind of ground: belts shield plastic cover, gear box in exclusive design, greasing system from the top. The original blades can be replaced by mulching blades, in case the operator wants to make mulching operations. It is currently available in three different sizes. Upon request it is possible to have the front roller and the solid tires. Standard equipment: air tires, universal 3 point hitch of 1rst cat., steering wheels adjustable for height, external belts adjustment, drive shaft.
|
Model |
FM120 |
FM150 |
FM180 |
|
Dimensions(L*W*H) |
1330×1200×600mm |
1630×1300×600mm |
1930×1400×600mm |
|
Structure weight |
195kg/429lbs |
210kg/462lbs |
230kg/506lbs |
|
Cutting width |
1190mm |
1490mm |
1790mm |
|
Working efficiency |
4000-10000m3/h |
4500-12000m3/h |
5000-15000m3/h |
|
PTO turnning speed |
540r/min |
540r/min |
540r/min |
|
PTO spline |
6×8×850 |
6×8×850 |
6×8×950 |
|
Power required |
18-25hp |
20-30hp |
20-35hp |
